Sale!

14’W x 30’L x 12’H – (Utility Building)

$2,448.00



The 14x30x12 portable building has a variety of uses to meet your needs. It can be used as a utility building, pickup trucks shelter, livestock shelter, boat storage unit, and more! It comes with a convenient roll up door kit for the front door and 2 double zipper doors that allow for easy drive-thru access.

The gambrel shape provides extra storage space along the sides and roof. Our pre-drilled frames make assembly easy. As with all of our products, this shelter is made of a heavy-duty galvanized steel frame and UV resistant and fire-retardant cover for lasting protection.



Included

  • 10 oz. UV Treatment Cover
  • 2 Double Zipper Doors-11’6″W x 9’8″H  (7’6″W at top)
  • 14 Cable Earth Anchor Kit
  • 1-5/8″ Galvanized Steel Frame
  • Roll Up Door Kit for front door included

SKU: N/A Category:

Description

Exclusive Features

  • Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life.
  • Easy Bolt Together Design – all Pre-drilled & Cut
  • Wind Brace Support on Both Sides
  • Two(2) Double Zipper Doors with Bottom Pockets
  • One (1) complete Roll-up Door Kit
  • Protective Plastic Tube End Caps – All Open Ends
  • Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
  • Quick Assembly Wrench included
  • Heavy Duty Poly Rope for Main Cover Tie Down
  • Heavy Duty Grommets on Cover & Doors
  • Five Box Shipment – easily unloaded and transported
  • Assembles in 4 hrs

Easy Fit Together Design – all Pre drilled & Cut

Pipe Size

Designed For Heavy Snow Load

Click here Fabric Details

permanent anchors

Click here for Steel Tubing Details

Standard Specifications

  • Nominal Size 14′ Wide x 30’ Long x 12′ High
  • Arches Seven (7 ) on 60″ spacing
    1-5/8″ diameter frame members
  • Standard End Door Size12′ wide x 10′ height at edge
    Double zipper door each end
  • Available Colors Outer Colors: Gray / Green / Tan
    All Interiors: Bright White Only
  • Shipping Weight460 Lbs. in Five (5) boxes shipped via motor freight
  • Pallet Dimensions
  • 40″ W x 84″L  x 24″
  • Box Dimensions
  • Box 1: 84″ Long x 17″ Wide x 4″ High
  • Box 2: 84″ Long x 17″ Wide x 5″ High
  • Box 3: 108″ Long x 30″ Wide x 4″ High
  • Box 4: 59″ Long x 12″ Wide x 4″ High
  • Box 5: 76″ Long x 28″ Wide x 5″ High
  • Main Cover
  • UV protected 24 mil, fabric backed poly. 10oz. weight
  • Fire Retardant Standard
  • Main Cover & Doors meet CPAI -84 Section 5
  • Anchors
  • Fourteen (14) Anchors with U-Bolts & 36″Drive Rod Std.
  • Stock Number
  • 14x30x12- PB143012RGN, PB143012RGY, PB143012RTN

Product Documentation

  • the product spec sheet
  • the assembly manual

Additional information

Dimensions 30 × 14 × 12 in
Color :

Green, Gray, Tan
